• To open the bottom assembly press and slide side cap locks in the direction of the arrow (Figure A)
• Drop in label roll with label backing facing up (Figure B)
• Pull 7" strip of the label tape out from the labeler and close the bottom assembly until it locks
• Feed labels straight down into the bottom drive assembly near the "Insert Label" text and arrow (Figure C)
• Squeeze the labeler handle to advance the strip of labels through the bottom assembly (Figure D)
• Within a few cycles, the labeler will align itself to print in the proper area of the label

Changing the Ink Roller:

• Ink roller is located behind the door at the nose of the labeler. Access the ink roller by pulling the front out and down (Figure E)
• Pinch the two tabs at the ends of the roller, then pull up and out to release the ink roller from its station (Figure F)
• Dispose the old ink roller and insert new ink roller
• Replace the ink roller by performing the steps above in reverse. Close the front protection plate
• NEVER re-ink an ink roller. The rollers are not designed to absorb ink
• Recommend changing the ink roller after every sleeve of labels for crisp clear print
